SSMP Male Right Angle Surface Mount RF Connector With Microstrip Smooth Bore

Ask Lasest Price
Brand Name :	ELT (Elite)
Model Number :	SSMP-JWHD9-S
Certification :	CE ROHS
Price :	Negotiable
Payment Terms :	Western Union, L/C, T/T
Supply Ability :	1,000,000pcs per month
Delivery Time :	Within 3 weeks

Add to Cart

Product Details
Company Profile

SSMP Male Right Angle Surface Mount RF Connector With Microstrip Smooth Bore

SSMP Male Right Angle Surface Mount with Microstrip Smooth Bore RF Connector Interface Depth2.11

Xi'an Elite Electronic designed the SSMP connector product line to further improve package density of RF/Microwave systems.

The SSMP interface is about 30% smaller than its predecessor, the SMP connector. Now an industry standard for RF/Microwave applications, the SSMP interface

Features

* Frequency Range: DC - 50 GHz
* 50 Ω Impedance; Blindmateable configuration
* Ability to withstand Radial/Axial Misalignment
* Board-mount, Field-replaceable, Bullets, Hermetic and Cable Connector configurations
* Custom Connectors Available

Specification

Electrical Characteristics
Impedance	50Ω
Frequency Range	DC~60GHz
Rated Voltage	85VRMS*
Dielectrics Voltage-resistance	250VRMS*
Insulation Resistance	≥2000MΩ
Center Resistance	Outer conductor		Normal≤2mΩ, Sealing≤5mΩ
	Center conductor		Normal≤6mΩ, Sealing≤25mΩ
	DC~18GHz	18~26.5GHz		26.5~40GHz	40~50GHz
VSWR	≤1.25	≤1.3		≤1.35	≤1.4
Material & Mechanical Characteristics
Center Conductor	Male		Sn-P Bronze/Kovar, Gold plated
	Female		Beryllium bronze, Gold plated
Elastic Contact	Beryllium bronze Gold plated
Shell and other Metal Parts	Brass/Kovar Gold plated Stainless steel Passivation
Insulators	Glass sintering/PTFE/PEI
Hermetic Product Leakage Rate	≤1.01325×10-3Pa·cm3/s

Application:

Antennas
Broadband
Wireless
Military
Instrumentation
Medical
Quantum Computing

Product Cataloge:

RF Adapter

Waveguide To Coaxial Adapter

TNC RF Connector

N Type RF Connector

Microwave Rotary Joints

RF Cable Assemblies

SMA/SSMA RF Connector

SMP/SSMP RF Connector

MCX/MMCX RF Connector

J30J Series Connector

Glass-to-metal Hermetic Seals

BNC RF ConnectorMillimeter Wave Connectors(2.4mm, 2.92mm)

Packaging Details:

* Standard Export Carton
* According to customers' requirements

NOTE:
We have over 10,000 types of SMPM Connector, if the connector you are using is not found, please contact us with your details.
