WR28 BJ320 To K2.92mm Female End Launch Waveguide To Coax Adapter 26.4GHz~40GHz

The frequency of wave-guide to coax adapters processed by Elite Electronic (ELT) cover 5.4GHz-110GHz. With high reliability, small size and excellent performance, it is widely used in microwave measurement and millimeter wave equipment. The waveguide has standard rectangular and double-ridge waveguides, and non-standard waveguides can be customized according to user requirements. The coaxial end connection interface includes N, TNC, SMA, SMP,SSMP, 3.5, K (2.92), 2.4, 1.85, 1.0 and microstrip. Waveguide to coax adapters are divided into two types: end Launch and right angle launch from interface orientation. Among them, the RA launch type can also be used as a high-power structure.

Specification of K/BJ320-KFE9:

Product Name	WR28 Waveguide to K2.92mm Coaxial Adapters
Model No.	K/BJ320-KFE9
Coaxial type	K2.92mm
Waveguide Size	WR28 (BJ320)
Body Style	End Launch
Frequency Range	26.4-40GHz
SMA Impedance	50 Ohm
VSWR	1.30

Advantages:

-Our waveguide adapters are of high reliability, miniature size and excellent performance etc, which makes them extensively adopted in microwave measurement and millimeter wave devices etc.

Outline Drawing and Pictures of WR28 BJ320 to 2.92mm Female Waveguide to Coax Adapter 2K/BJ320-KFE9:

List of Waveguide to 2.92mm Coaxial Adapters:

Model Number	Description	Note
K/BJ320-KF22	WR28(BJ320) to 2.92mm female right angle adapters
K/BJ320-KFE9	WR28(BJ320) to 2.92mm female end launch adapters	BJ320=WR28
Custom Type	Customized sizes are acceptable

Cross-references of waveguide Standards

Chinese Standards	International Standards	Frequency Range (GHz)
BJ84	WR112	6.57~9.99
BJ100	WR90	8.20~12.5
BJ120	WR75	9.84~15.0
BJ140	WR62	11.9~18.0
BJ180	WR51	14.5~22.0
BJ220	WR42	17.6~26.7
BJ260	WR34	21.7~33.0
BJ320	WR28	26.3~40.0
BJ400	WR22	32.9~50.1
BJ500	WR18	39.2~59.6
BJ620	WR14	49.8~75.8
BJ740	WR12	60.5~91.9
BJ900	WR10	73.8~112

Waveguide to Coax Adapter-ELT 2024.pdf

NOTE:
We have over 1,000 types of Waveguide to Coaxial Adapters for choice, if the adapter you are using is not found, please contact us with your details. ODM dimension is welcomed.
